0 - 1,600 (kg)
0 - 5,316 (mm)

L14–L16 R

Comfortable high-reach

Fatigue-free working in all situations

The L14–L16 R pallet stackers can achieve lifting heights of up to 5316 millimetres. Thanks to the optional initial lift and overhead guard, they are also suitable for safe loading and unloading of trucks via ramps or bridge plates. With a compact width of 820 mm, the truck is both manoeuvrable and comfortable. Due to a lateral and raised seating position, operators have the best view of the loads and their surroundings. The vehicles are equipped with a powerful 3 kW engine and reach speeds of up to 10 km/h. In ECO mode, energy consumption is reduced by 12 percent.

Characteristics

Safety

The operator's body is situated safely inside the chassis contour at all times. The overhead guard provides additional safety against falling loads. Operators receive further support from the optional Linde Load Management system. It measures data such as residual capacity and warns the operator when the load reaches the permissible limit. An automatic levelling system also ensures that all wheels continuously touch the ground, thus stabilising the vehicle. For safe handling, the soft landing function automatically brakes the forks so that loads can be lowered very gently.

All-round protection for the operator
Overhead guard
Optional Linde Load Management
Fork lowering with soft landing function

Ergonomics

The seat is turned 90° to the direction of travel and has three independent adjustment options and integrated control elements. This allows the operator to assume an optimal position in which they can work without fatigue. The height of the operator's workstation can be adjusted to best suit the operator by means of an adjustable foot platform. A padded entry handle also provides easy access to the vehicle.

Lateral sitting position
Three individual seat settings
Adjustable base plate
Padded entry handle

Handling

The L14–L16 R pallet stackers are equipped with a powerful 3 kW three-phase AC motor and reach speeds of up to 10 km/h. The robust chassis offers high residual capacities of 1400 to 1600 kg. This combination ensures high productivity. The compact 820 mm-wide chassis and the intuitive one-handed control also provide excellent manoeuvrability even in confined work environments. The lateral battery replacement is particularly easy thanks to metal rollers in the battery compartment.

Residual capacities from 1400 to 1600 kg
Compact for optimum manoeuvrability
One-hand control
Easy battery replacement

Service

Thanks to easily accessible components and the use of maintenance-free technologies, the trucks in the L14–L16 R series can be operated cost-effectively and with high vehicle availability. The modern CAN bus connection enables efficient maintenance, as all system data can be accessed quickly and reliably via notebook.

Easy maintenance access
Maintenance-free components
High vehicle availability
Fast diagnosis through CAN bus connection

Technical Data

Model	Load capacity/Load	Lift	Travel speed, with/without load	Turning radius	Battery voltage/rated capacity (5h)
L14R	1.4 (t)	2844 (mm)	10 / 10 km/h	1783 (mm)	24 / 345/375 [23/205] (V)/(Ah) o. kWh
L14Ri	1.4 / (2.0) (t)	2844 (mm)	10 / 10 km/h	1783 (mm)	24 / 345/375 [23/205] (V)/(Ah) o. kWh
L16R	1.6 (t)	2844 (mm)	10 / 10 km/h	1783 (mm)	24 / 345/375 [23/205] (V)/(Ah) o. kWh
L16Ri	1.6 / (2.0) (t)	2844 (mm)	10 / 10 km/h	1783 (mm)	24 / 345/375 [23/205] (V)/(Ah) o. kWh

Download Datasheet

Heated leather seats

Leather seats and adjustable seat heating increase operator comfort when used in cold storage or in cold environments.

Flexible lift mast heights

Standard, duplex and triplex masts are available to customers to meet the wide range of application requirements. For greater lifting heights, a duplex mast is used. This mast has an additional inner mast profile, which almost doubles the lifting height. A triplex mast is equipped with two internal mast profiles lying one inside the other. The electric pallet stacker L14–L16 R achieves lifting heights of up to 5316 mm.

Linde Load Management Advanced

The Linde Load Management assistance system calculates the maximum possible height and weight in real time on the basis of residual capacity. This increases safety and productivity during handling.
