V modular

The wide cabin entrance and low entry height facilitate access to the V modular, while the low railing makes it easier to pick up and put down goods. A soft floor mat cushions vibrations and prevents operator fatigue. The operator can work comfortably in the spacious operator’s compartment. A convenience cover on the mast end of the cabin is available on request, and this offers additional storage space e.g. for a bin or wrapping foil. The patented ergo pad from Linde allows the operator to lean back, relieving muscle tension. The control panel of the V modular can be mounted on the mast end, load end or on both ends depending on the requirements. The colour display allows the operator to keep an eye on important parameters such as speed, lifting height, remaining load capacity and steering angle. The display also provides information from optional systems such as Linde Warehouse Navigation. The truck can optionally be equipped with tilting barriers, which easily fold outwards when the operator leans against them, therefore making it easier to access the racking.

The V modular reaches picking heights of up to 14.5 metres and speeds of up to 13 km/h, optimising handling performance in the high rack warehouse. In addition, high lifting speeds and residual load capacities, as well as low energy consumption, make the truck extremely efficient. At the same time, a redesigned chassis and improved load arms guarantee greater stability and optimum manoeuvrability. Linde offers two triplex masts for the V modular. The standard version with free lift is particularly suitable for warehouses with structural restrictions, such as racks over the transfer aisle. The variant without free lift allows for quicker lifting because the speed does not need to be reduced during the mast transition. In addition to the standard version with additional lift, the V modular is also available with walk-on pallet, in which case the forks are fixed on the truck and surrounded by a safety cage. The cabin is open on the fork side, meaning that the operator can access the pallet for order picking. An innovative control concept ensures that all travel and mast movements transition fluently into each other.

The travel and lift motors of the V modular are fully encapsulated. As a result, they are completely protected from dust and dirt and almost maintenance-free, which improves the availability of the trucks and drastically reduces costly downtimes. The entire design is optimised for easy servicing. The central components are behind a screen, making it simple and quick for service technicians to access them. The technician can check all data easily on the service laptop via a CAN-bus connection. To simplify fault analysis, all narrow-aisle trucks from Linde have the same diagnosis connection.
